windows xp only
K150 , programmation pic,is a low-cost high-performance PIC programmer, supporting the most popular PIC chips.
This device is obsolete and not compatible with MPLab X (new PIC development tool), so you will have to export files in HEX format from MPLab X and import to DIY application which has released last version in 2007. For small projects this device is fine but for more advanced development is recommended usage of PICKit 3
Features:
Support the most popular programming PIC chips, read, encryption and other features!
No external power supply required, communication and power by supplied USB cable.
With 40pin ZIF socket, 8-pin to 40 pin PIC microcontroller chip can easily be programmed.
8 pin 40 pin-board Allows programming of PIC device whilst in circuit via its ICSP and included cable.
Compatible with Windows98 and Windows2000/NT, Windows XP to Windows 7.
Programming software provides easy to use instructions.
programmation pic
Pinout Information for ICSP (pin 1 count from middle to pin 6 at the edge):
Pin 1 ~ Vpp (MCLR/ Reset)
Pin 2 ~ Vcc (5 Volt DC)
Pin 3 ~ Gnd (Ground)
Pin 4 ~ Data
Pin 5 ~ Clock (CLK)
Pin 6 ~ PGM (LVP)
Tutorial Link
Support Chip List
12F Series:
PIC12F508 PIC12F509 PIC12F629 PIC12F635
PIC12F675 PIC12F683
16F Series:
PIC16F505 PIC16F506 PIC16F54 PIC16F57 *
PIC16F59 * PIC16F627 PIC16LF627A PIC16F627A
PIC16F628 PIC16LF628A PIC16F628A PIC16F630
PIC16F631 * PIC16F631-1 * PIC16F636 PIC16F636-1
PIC16F639 * PIC16F639-1 * PIC16F648A PIC16F676
PIC16F677 PIC16F677-1 PIC16F684 PIC16F685 *
PIC16F685-1 * PIC16F687 * PIC16F687 *- 1 PIC16F688
PIC16F689 * PIC16F689-1 * PIC16F690 * PIC16F690-1 *
PIC16F716 PIC16F72 PIC16F73 PIC16F74
PIC16F76 PIC16F77 PIC16F737 PIC16F747
PIC16F767 PIC16F777 PIC16F83 PIC16F84
PIC16F84A PIC16F87 PIC16F88 PIC16F818
PIC16F819 PIC16F870 PIC16F871 PIC16F872
PIC16F873 PIC16F873A PIC16LF873A PIC16F874
PIC16F874A PIC16F876 PIC16F876A PIC16F877
PIC16F877A
18 Series:
PIC18F242 PIC18F248 PIC18F252 PIC18F258 PIC18F442 PIC18F448
PIC18F452 PIC18F458 PIC18F1220 PIC18F1320 PIC18F2220 PIC18F2320
PIC18F2321 PIC18F4210 PIC18F2331 PIC18F2450 PIC18F2455 PIC18F2480
PIC18F2510 PIC18F2515 PIC18F2520 PIC18F2525 PIC18F2550 PIC18F2580
PIC18F2585 PIC18F2610 PIC18F2620 PIC18F2680 PIC18F4220 PIC18F4320
PIC18F6525 PIC18F6621 PIC18F8525 PIC18F8621 PIC18F2331 PIC18F2431
PIC18F4331 PIC18F4431 PIC18F2455 PIC18F2550 PIC18F4455 PIC18F4550
PIC18F4580 PIC18F2580 PIC18F2420 PIC18F2520 PIC18F2620 PIC18F6520
PIC18F6620 PIC18F6720 PIC18F6585 PIC18F6680 PIC18F8585 PIC18F8680
*via ICSP only.
